Roomcontroller solo

Roomcontroller solo

Room Control reduced to the maximum

  • fits into standard flush-mounted box
  • with temperature sensor
  • individual user interface

Wherever a standard switch fits, it also fits solo – the intelligent replacement for conventional KNX switches. This gives you a control element that not only impresses with its elegant design, but also impresses with its comprehensive functionality.

The touch surface with a 4-inch diagonal can also be operated without contact using gestures. It can installed in a standard built-in box or in built-in box for flush mounting (EPG). Thanks to the integrated temperature sensor, solo saves a separate room thermostat.

For anything less you should not feel satisfied:

  • elegant design with a frameless real glass front
  • latest browser technology
  • anti-theft installation
  • brightness sensor to control the light intensity
  • individual surface for an unmistakable design

With solo you can implement customized operating concepts for your customers. Essential functions in the room, such as switching the light on and off, controlling the shading or specifying the room temperature, are directly available with solo.

Extended functions with solo+

  • integrated air quality sensor (temperature, humidity, air quality, air pressure)
  • as video intercom for door communication
  • WLAN - ideal for retrofitting
  • locally and useable without a cloud

Diverse application possibilities

  • Smart Home
  • house building
  • hotels and conference rooms
  • offices and trade
Request now Download Datasheet



Mounting in a standard built-in box


Mounting in EPG


solo+: Mounting in a standard double socket


solo+: Mounting in EPG

Product information at a glance

Technical data

  • roomcontroller for building automation
  • 4“ multitouch with continuous glass surface, 300cd / m²
  • embedded VI Board
  • rockchip RK3288 CPU
  • IP20
  • PoE
  • ethernet 10/100
  • 1x Micro USB
  • temperature sensor and connection for temperature sensor
  • optional: KNX
  • optional: RS-485
  • working temperature: 0 bis 35°C
  • storage temperature: -20 bis 70°C
  • relative humidity: 10 up to 80%, not condensing
  • power input:  24 VDC and PoE
    IEEE Std 802.3af (Class 0)

Order info


Roomcontroller / touch switch with 4 "multi-touch, continuous glass surface, Android 9 (Pie) with the WebWizard installed
Design: black


Roomcontroller as solo expanded with integrated air quality sensor, video intercom for door communication, WLAN

Additional equipment


Operating systems

Linux (Version on request)


EPG - Built-in box for flush mounting (including HMK)
EPG for solo+ - Built-in box for flush mounting (including HMK)
