Touch Panel Edition4
Modern visualization and control solution
- Exclusive touch PC, hand made
- Choose your bus-system
- Simple one-man installation with Rapid mounting
- Fits in housings from various manufacturers
Modern visualization control solution
Our Edition4 Touch Panel is a modern visualization and control solution that impresses above all with its technical sophistication and timelessly elegant design. The precision-crafted multi-touch glass front creates a stylish ambience and—available in black or white glass—can be flexibly combined with a wide variety of interior design styles.
Our Edition4 also offers complete flexibility in terms of mounting options. You can install the touch panel either as a simple surface-mounted version or as a flush-mounted version. Here, too, the click mechanism allows for easy installation in the flush-mounted housing.
In addition, it is equipped with a microphone and active speakers as standard.
Our Edition4 is therefore ideally suited as a central point of contact for media control, door intercom and video communication throughout the house.
Variants
![]() Mounting in white APG
|
![]() Mounting in black APG
|
![]() Mounting in UPG
|
![]() Mounting in UPG
|
These pictures show the Edition4 in different installation situations and design variants
Product information at a glance
Technical data
- Touch Panel PC for wall mounting
as 10,1 and 12,1 Zoll also for onwall mounting - TFT-LCD Display, in sizes 10,1″, 12,1″ and 15,6″
- 16" optionally also as display (TD) available
- excellent haptic with glass multitouch
- speaker, microphone
- working temperature: 0 up to 40°C
- storage temperature -20 up to 60°C
- relative humidity: 10 up to 80%, not condensing
- power input:
PC102 / PC121 / PC121 AP: 12 - 24VDC
PC102 AP: 12 – 24VDC / optional 230VAC
PC156: 110 – 240VAC or 12VDC
Order info
Display |
Projective Capacitive Multitouch in different display resolutions |
Design |
Cover glass black or white
Onwall-mounted housing black or white
|
Equipment |
PC102 / PC102AP / PC121 / PC121AP:
Intel Celeron N3350 CPU, Intel HD Graphics, fanless, 1x HDMI, 1x RJ45 LAN, 2x USB3.0, 1x 24V DC, 8GB DDR3, 128GB SSD, speakers, microphone, Windows 10 IoT LTSC 2021
PC156: Intel Celeron J6412 CPU, Intel UHD Grafik, fanless, 2x HDMI, 2x RJ45 LAN, 4x USB3.2, 8GB DDR3, 128GB SSD, speakers, microphone, Windows 10 IoT LTSC 2021
Optional: Intel i5 1135G7 CPU, Intel Iris Grafik, fanless, 2x HDMI, 2x RJ45 LAN, 4x USB3.2, 1x COM Port, 16GB DDR3
|
Power consumption
Operating status |
Last (P in W)
|
Standby (P in W)
|
PC102 / PC102 AP
|
12
|
1,2
|
PC121 / PC121 AP |
23
|
-
|
TD156
|
15
|
0.5
|
PC156 (Celeron J6412 | Intel i5)
|
26 | 34
|
5 | 5
|
Additional equipment
Operating systems |
Linux
|
Mounting |
UPG - Built-in box
APG - Housing for on wall installation
|
